P4 Full Color LED Display

Product Overview

The P4 Full Color LED Display by Brandon Optoelectronics is a robust visual solution engineered for outdoor fixed installations and mid-to-large scale stage applications. As a 13-year source manufacturer, we integrate high-quality SMD technology with a durable die-cast aluminum structure to deliver stable, high-impact visuals. This display is designed for environments requiring a balance of definition and cost-efficiency, making it a reliable choice for outdoor advertising and permanent stage backdrops.

Core Specifications

• Pixel Pitch: P4mm
• Cabinet Material: Die-cast Aluminum (Lightweight & Durable)
• Brightness: 1200-2000 nits (Adjustable)
• Refresh Rate: ≥1920Hz
• Viewing Angle: H140° / V120°
• Protection Level: IP43 (Outdoor)
• Cabinet Resolution: 256 x 128mm
• Special Features: Quick-assembly, Seamless Splicing, Anti-static, High Contrast

Application Scenarios

• Outdoor Fixed Installations: Ideal for building facades, plazas, and commercial streets where long-term reliability is required.
• Stage Backdrops: Suitable for concert tours, product launches, and theater productions requiring a balance of visual impact and budget.
• Outdoor Advertising: Used in high-traffic areas for brand promotion and digital signage.
• Corporate Functions: Perfect for large-scale outdoor presentations and product unveiling ceremonies.

Installation Environment

• Outdoor Use: Designed for outdoor environments with protection against dust and water splashes (IP43).
• Structural Support: Supports wall-mounted, floor-standing, and suspended installations. Ensure the structural support can bear the weight of the display.
• Ventilation: Adequate ventilation is required behind the screen to ensure efficient heat dissipation.
• Accessibility: Plan for easy access to power connections and control systems for maintenance.

Viewing Distance

• Optimal Viewing Distance: 4 meters to 80 meters
• Recommended Viewing Angle: Wide viewing angle suitable for multi-directional audiences
• Note: The P4 pitch offers a balance between high definition and visual impact, making it ideal for venues where the audience is positioned at a moderate to long distance. The high refresh rate ensures smooth video playback without flickering, suitable for dynamic content.

Adjacent Pitch Comparison

• P4 vs P3 vs P5 (Outdoor Context)
• Clarity: P3 > P4 > P5
• Cost-Effectiveness: P5 > P4 > P3
• Use Case Recommendations
• P3: Detailed imagery requirements for medium-distance viewing (3-60m), such as high-end indoor/outdoor stages.
• P4: General outdoor fixed installations or mid-sized stages requiring a balance of budget and visual impact (4-80m).
• P5: Large-area outdoor installations where cost efficiency is prioritized over fine detail (5-100m).

Selection Guide

• Define Usage: Determine if the application requires fixed installation or rental use based on mobility needs.
• Measure Space: Calculate the available height and width to ensure the screen fits within the designated area.
• Assess Viewing Distance: Choose the pitch based on the audiences proximity. For 4-80 meters, P4 offers a balanced solution.
• Plan Installation: Select wall-mounted, floor-standing, or suspension methods based on site conditions and structural support availability.
• Budget Consideration: Balance visual requirements with cost, considering that smaller pitches provide higher definition at a higher price point.

Extended Keywords

• Core Terms: P4 Full Color LED Display, Outdoor LED Screen, P4 LED Display, Fixed Installation LED
• Long-tail Terms: Die-cast Aluminum LED, Quick-assembly LED Screen, Seamless Splicing LED, Outdoor Advertising LED
• Scenario Terms: Concert Tour LED, Wedding Hall LED, Conference Hall LED, Broadcast Studio LED
• Attribute Terms: High Refresh Rate LED, Plug-and-Play LED, Anti-corrosion LED, Outdoor Advertising LED

FAQ

• Q: Can the screen display custom content?
  A: Yes. The display supports standard video formats and can be customized to play specific content based on your creative needs.
• Q: Is the screen suitable for extreme outdoor conditions?
  A: Yes. The display operates reliably in temperatures ranging from -20°C to 60°C, suitable for most outdoor environments.
• Q: What is the minimum order quantity for custom sizes?
  A: As a source manufacturer, we support OEM/ODM services with flexible MOQ. Please contact us for specific customization details.
• Q: Can the screen be controlled remotely?
  A: Yes. The display supports standard control systems for remote content management and scheduling.
